codegen

Code generator in Haskell that produces hyper-optimized Go code for elliptic curve computations over finite fields of a certain size (e.g. Curve25519).

Independent directed research project advised by Prof. Bryan Ford.



For example, the multiplication function outputted by the generator looks something like this:

void fe_mul(fe h, fe f, fe g)
{
  crypto_int32 f0 = f[0];
  crypto_int32 f1 = f[1];
  crypto_int32 f2 = f[2];
  crypto_int32 f3 = f[3];
  crypto_int32 f4 = f[4];
  crypto_int32 f5 = f[5];
  crypto_int32 f6 = f[6];
  crypto_int32 f7 = f[7];
  crypto_int32 f8 = f[8];
  crypto_int32 f9 = f[9];

  crypto_int32 g0 = g[0];
  crypto_int32 g1 = g[1];
  crypto_int32 g2 = g[2];
  crypto_int32 g3 = g[3];
  crypto_int32 g4 = g[4];
  crypto_int32 g5 = g[5];
  crypto_int32 g6 = g[6];
  crypto_int32 g7 = g[7];
  crypto_int32 g8 = g[8];
  crypto_int32 g9 = g[9];

  crypto_int32 g0_19 = 19 * g0;
  crypto_int32 g1_19 = 19 * g1;
  crypto_int32 g2_19 = 19 * g2;
  crypto_int32 g3_19 = 19 * g3;
  crypto_int32 g4_19 = 19 * g4;
  crypto_int32 g5_19 = 19 * g5;
  crypto_int32 g6_19 = 19 * g6;
  crypto_int32 g7_19 = 19 * g7;
  crypto_int32 g8_19 = 19 * g8;
  crypto_int32 g9_19 = 19 * g9;

  crypto_int32 f1_2 = 2 * f1;
  crypto_int32 f3_2 = 2 * f3;
  crypto_int32 f5_2 = 2 * f5;
  crypto_int32 f7_2 = 2 * f7;
  crypto_int32 f9_2 = 2 * f9;

  f0g0 = f0 * (crypto_int64) g0;
  f0g1 = f0 * (crypto_int64) g1;
  f0g2 = f0 * (crypto_int64) g2;
  f0g3 = f0 * (crypto_int64) g3;
  f0g4 = f0 * (crypto_int64) g4;
  f0g5 = f0 * (crypto_int64) g5;
  f0g6 = f0 * (crypto_int64) g6;
  f0g7 = f0 * (crypto_int64) g7;
  f0g8 = f0 * (crypto_int64) g8;
  f0g9 = f0 * (crypto_int64) g9;
  f1g0 = f1 * (crypto_int64) g0;
  f1g1_2 = f1_2 * (crypto_int64) g1;
  f1g2 = f1 * (crypto_int64) g2;
  f1g3_2 = f1_2 * (crypto_int64) g3;
  f1g4 = f1 * (crypto_int64) g4;
  f1g5_2 = f1_2 * (crypto_int64) g5;
  f1g6 = f1 * (crypto_int64) g6;
  f1g7_2 = f1_2 * (crypto_int64) g7;
  f1g8 = f1 * (crypto_int64) g8;
  f1g9_38 = f1_2 * (crypto_int64) g9_19;
  f2g0 = f2 * (crypto_int64) g0;
  f2g1 = f2 * (crypto_int64) g1;
  f2g2 = f2 * (crypto_int64) g2;
  f2g3 = f2 * (crypto_int64) g3;
  f2g4 = f2 * (crypto_int64) g4;
  f2g5 = f2 * (crypto_int64) g5;
  f2g6 = f2 * (crypto_int64) g6;
  f2g7 = f2 * (crypto_int64) g7;
  f2g8_19 = f2 * (crypto_int64) g8_19;
  f2g9_19 = f2 * (crypto_int64) g9_19;
  f3g0 = f3 * (crypto_int64) g0;
  f3g1_2 = f3_2 * (crypto_int64) g1;
  f3g2 = f3 * (crypto_int64) g2;
  f3g3_2 = f3_2 * (crypto_int64) g3;
  f3g4 = f3 * (crypto_int64) g4;
  f3g5_2 = f3_2 * (crypto_int64) g5;
  f3g6 = f3 * (crypto_int64) g6;
  f3g7_38 = f3_2 * (crypto_int64) g7_19;
  f3g8_19 = f3 * (crypto_int64) g8_19;
  f3g9_38 = f3_2 * (crypto_int64) g9_19;
  f4g0 = f4 * (crypto_int64) g0;
  f4g1 = f4 * (crypto_int64) g1;
  f4g2 = f4 * (crypto_int64) g2;
  f4g3 = f4 * (crypto_int64) g3;
  f4g4 = f4 * (crypto_int64) g4;
  f4g5 = f4 * (crypto_int64) g5;
  f4g6_19 = f4 * (crypto_int64) g6_19;
  f4g7_19 = f4 * (crypto_int64) g7_19;
  f4g8_19 = f4 * (crypto_int64) g8_19;
  f4g9_19 = f4 * (crypto_int64) g9_19;
  f5g0 = f5 * (crypto_int64) g0;
  f5g1_2 = f5_2 * (crypto_int64) g1;
  f5g2 = f5 * (crypto_int64) g2;
  f5g3_2 = f5_2 * (crypto_int64) g3;
  f5g4 = f5 * (crypto_int64) g4;
  f5g5_38 = f5_2 * (crypto_int64) g5_19;
  f5g6_19 = f5 * (crypto_int64) g6_19;
  f5g7_38 = f5_2 * (crypto_int64) g7_19;
  f5g8_19 = f5 * (crypto_int64) g8_19;
  f5g9_38 = f5_2 * (crypto_int64) g9_19;
  f6g0 = f6 * (crypto_int64) g0;
  f6g1 = f6 * (crypto_int64) g1;
  f6g2 = f6 * (crypto_int64) g2;
  f6g3 = f6 * (crypto_int64) g3;
  f6g4_19 = f6 * (crypto_int64) g4_19;
  f6g5_19 = f6 * (crypto_int64) g5_19;
  f6g6_19 = f6 * (crypto_int64) g6_19;
  f6g7_19 = f6 * (crypto_int64) g7_19;
  f6g8_19 = f6 * (crypto_int64) g8_19;
  f6g9_19 = f6 * (crypto_int64) g9_19;
  f7g0 = f7 * (crypto_int64) g0;
  f7g1_2 = f7_2 * (crypto_int64) g1;
  f7g2 = f7 * (crypto_int64) g2;
  f7g3_38 = f7_2 * (crypto_int64) g3_19;
  f7g4_19 = f7 * (crypto_int64) g4_19;
  f7g5_38 = f7_2 * (crypto_int64) g5_19;
  f7g6_19 = f7 * (crypto_int64) g6_19;
  f7g7_38 = f7_2 * (crypto_int64) g7_19;
  f7g8_19 = f7 * (crypto_int64) g8_19;
  f7g9_38 = f7_2 * (crypto_int64) g9_19;
  f8g0 = f8 * (crypto_int64) g0;
  f8g1 = f8 * (crypto_int64) g1;
  f8g2_19 = f8 * (crypto_int64) g2_19;
  f8g3_19 = f8 * (crypto_int64) g3_19;
  f8g4_19 = f8 * (crypto_int64) g4_19;
  f8g5_19 = f8 * (crypto_int64) g5_19;
  f8g6_19 = f8 * (crypto_int64) g6_19;
  f8g7_19 = f8 * (crypto_int64) g7_19;
  f8g8_19 = f8 * (crypto_int64) g8_19;
  f8g9_19 = f8 * (crypto_int64) g9_19;
  f9g0 = f9 * (crypto_int64) g0;
  f9g1_38 = f9_2 * (crypto_int64) g1_19;
  f9g2_19 = f9 * (crypto_int64) g2_19;
  f9g3_38 = f9_2 * (crypto_int64) g3_19;
  f9g4_19 = f9 * (crypto_int64) g4_19;
  f9g5_38 = f9_2 * (crypto_int64) g5_19;
  f9g6_19 = f9 * (crypto_int64) g6_19;
  f9g7_38 = f9_2 * (crypto_int64) g7_19;
  f9g8_19 = f9 * (crypto_int64) g8_19;
  f9g9_38 = f9_2 * (crypto_int64) g9_19;

  crypto_int64 h0 = f0g0 + f1g9_38 + f2g8_19 + f3g7_38 + f4g6_19 + f5g5_38 + f6g4_19 + f7g3_38 + f8g2_19 + f9g1_38;
  crypto_int64 h1 = f0g1 + f1g0 + f2g9_19 + f3g8_19 + f4g7_19 + f5g6_19 + f6g5_19 + f7g4_19 + f8g3_19 + f9g2_19;
  crypto_int64 h2 = f0g2 + f1g1_2 + f2g0 + f3g9_38 + f4g8_19 + f5g7_38 + f6g6_19 + f7g5_38 + f8g4_19 + f9g3_38;
  crypto_int64 h3 = f0g3 + f1g2 + f2g1 + f3g0 + f4g9_19 + f5g8_19 + f6g7_19 + f7g6_19 + f8g5_19 + f9g4_19;
  crypto_int64 h4 = f0g4 + f1g3_2 + f2g2 + f3g1_2 + f4g0 + f5g9_38 + f6g8_19 + f7g7_38 + f8g6_19 + f9g5_38;
  crypto_int64 h5 = f0g5 + f1g4 + f2g3 + f3g2 + f4g1 + f5g0 + f6g9_19 + f7g8_19 + f8g7_19 + f9g6_19;
  crypto_int64 h6 = f0g6 + f1g5_2 + f2g4 + f3g3_2 + f4g2 + f5g1_2 + f6g0 + f7g9_38 + f8g8_19 + f9g7_38;
  crypto_int64 h7 = f0g7 + f1g6 + f2g5 + f3g4 + f4g3 + f5g2 + f6g1 + f7g0 + f8g9_19 + f9g8_19;
  crypto_int64 h8 = f0g8 + f1g7_2 + f2g6 + f3g5_2 + f4g4 + f5g3_2 + f6g2 + f7g1_2 + f8g0 + f9g9_38;
  crypto_int64 h9 = f0g9 + f1g8 + f2g7 + f3g6 + f4g5 + f5g4 + f6g3 + f7g2 + f8g1 + f9g0;

  crypto_int64 carry0;
  crypto_int64 carry1;
  crypto_int64 carry2;
  crypto_int64 carry3;
  crypto_int64 carry4;
  crypto_int64 carry5;
  crypto_int64 carry6;
  crypto_int64 carry7;
  crypto_int64 carry8;
  crypto_int64 carry9;

  carry0 = (h0 + (crypto_int64) (1 << 25)) >> 26;
  h1 += carry0;
  h0 -= carry0 << 26;

  carry4 = (h4 + (crypto_int64) (1 << 25)) >> 26;
  h5 += carry4;
  h4 -= carry4 << 26;

  carry1 = (h1 + (crypto_int64) (1 << 24)) >> 25;
  h2 += carry1;
  h1 -= carry1 << 25;

  carry5 = (h5 + (crypto_int64) (1 << 24)) >> 25;
  h6 += carry5;
  h5 -= carry5 << 25;

  carry2 = (h2 + (crypto_int64) (1 << 25)) >> 26;
  h3 += carry2;
  h2 -= carry2 << 26;

  carry6 = (h6 + (crypto_int64) (1 << 25)) >> 26;
  h7 += carry6;
  h6 -= carry6 << 26;

  carry3 = (h3 + (crypto_int64) (1 << 24)) >> 25;
  h4 += carry3;
  h3 -= carry3 << 25;

  carry7 = (h7 + (crypto_int64) (1 << 24)) >> 25;
  h8 += carry7;
  h7 -= carry7 << 25;

  carry4 = (h4 + (crypto_int64) (1 << 25)) >> 26;
  h5 += carry4;
  h4 -= carry4 << 26;

  carry8 = (h8 + (crypto_int64) (1 << 25)) >> 26;
  h9 += carry8;
  h8 -= carry8 << 26;

  carry9 = (h9 + (crypto_int64) (1 << 24)) >> 25;
  h0 += carry9 * 19;
  h9 -= carry9 << 25;

  carry0 = (h0 + (crypto_int64) (1 << 25)) >> 26;
  h1 += carry0;
  h0 -= carry0 << 26;

  h[0] = h0;
  h[1] = h1;
  h[2] = h2;
  h[3] = h3;
  h[4] = h4;
  h[5] = h5;
  h[6] = h6;
  h[7] = h7;
  h[8] = h8;
  h[9] = h9;
}
